XBee's DIN (RX) is connected to pin 11 (Arduino's Software TX) XBee's DOUT (TX) is connected to pin 10 (Arduino's Software RX) XBee's DIN (RX) is connected to pin 3 (Arduino's Software TX) XBee's DOUT (TX) is connected to pin 2 (Arduino's Software RX) We'll use SoftwareSerial to communicate with the XBee: The XBee's DOUT and DIN pins to Arduino pins 2 and 3. Sure the SWITCH IS IN THE "DLINE" POSITION. The XBee Shield makes all of the connections you'll needīetween Arduino and XBee.

ARDUINO BLUETOOTH DONGLE TUTORIAL SERIAL

Set up a software serial port to pass data between an XBee Shield Before uploading this sketch, make sure the switch on the Shield is in the "DLINE" position!Ĭopy and upload the sketch below. It makes use of the SoftwareSerial library, which is included with all of the recent Arduino releases. The second example uses the native hardware serial defined pins. The first uses software serial defined pins on an Arduino.

This sketch can be use to create a "portal of communication" between your Arduino's serial monitor, and another XBee (connected to a computer via a USB Explorer). In this section, we'll upload a sketch which passes data between your serial monitor and the XBe using the serial UART. Assembly Tipsīefore you can use the XBee Shield with your Arduino, you'll need to solder in some headers. The RSSI LED is actually PWM'd so it will be brighter when the paired XBee is closer (sending a stronger signal). The DIO5/Associate indicator should blink when the XBee is paired with a compatible device. These LEDs can be very useful for debugging. Indicates relative signal strength (RSSI) of last received transmission. Indicates wireless data is being transmitted. Indicates wireless data is being received. Here's a table explaining the operation of each LED: LED LabelĪssociated indicator - blinks when the XBee is associated with another XBee. Each of these LEDs connects to a pin on the XBee, which does most of the LED driving. At the very least, make sure the switch is in the "DLINE" position when uploading sketches. "D_TX" connects to Arduino pin 3, and "D_RX" connects to Arduino pin 2.įor all of our example sketches we'll assume the switch is in the DLINE position. The switch configuration from the XBee Shield schematic. For more help picking an XBee, check out our XBee Buying Guide.If you're just getting started with XBee, we highly recommend going with Series 1 models - either with a trace antenna, wire antenna or u.fl connector. 1x Arduino - The XBee Shield should work with any Arduino-compatible board - Uno, RedBoard, Mega, you name it.Ģx XBees - XBees exist in a variety of series, frequencies, and ranges.

ARDUINO BLUETOOTH DONGLE TUTORIAL INSTALL

You'll also need headers to install into your shield.

1x XBee Shield - The star of this tutorial.

Add it to your cart, read through the guide, and adjust the cart as necessary. You may not need everything though depending on what you have. To follow along with this tutorial, you will need the following materials. Then we'll move on to the remote control Arduino sketch. First we'll set up a test program to make sure our XBees are communicating with each other. We'll begin by examining the schematics and hardware of the XBee Shield, then move on to example code.
